Description
The manual is structured to provide service personnel with all necessary technical data, maintenance procedures, and component information.
-
Service Manual (Title Page): Identifies the document as Order No. ARP2743, covering the CLD-97 and CLD-98 models.
-
Model/Power Requirement Table: Specifies power requirements based on the model variation:
-
CLD-97 (KU/CA): AC120V only.
-
CLD-98 (KU/CA): AC120V only.
-
CLD-97/98 (SD): AC110V, 120V – 127V, 220V, 240V (switchable).
-
-
-
1. SAFETY INFORMATION: Essential warnings and special safety procedures for servicing.
-
WARNING/NOTICE/REMARQUE: Alerts regarding lead content, fuse symbols/replacement, and a general caution that the manual is not for the casual repairer.
-
1. SAFETY PRECAUTIONS: Requirements for performing a Leakage Current Check on all exposed metal parts before returning the appliance to the customer. A diagram illustrates the procedure (AC Leakage Test).
-
2. PRODUCT SAFETY NOTICE: Discusses critical safety-related characteristics and the use of identical or Pioneer-specified replacement components, emphasizing components marked with a $\triangle$ on schematics and parts lists.
-
